Network

Technology

• GSM / CDMA / HSPA / EVDO / LTE / 5GLaunch

Announced

• 2024, July 10Status

• Available. Released 2024, July 24Body

Dimensions

• Unfolded: 153.5 x 132.6 x 5.6 mm
• Folded: 153.5 x 68.1 x 12.1 mmWeight

• 239 g (8.43 oz)Build

• Glass front (Gorilla Glass Victus 2) (folded)
• Plastic front (unfolded)
• Glass back (Gorilla Glass Victus 2)
• Aluminum frameSIM

• Nano-SIM + eSIM
• eSIM + eSIM
• Nano-SIM + Nano-SIM (SM-F9560)Protection

• IP48 dust and water resistant (up to 1.5m for 30 min)
• Armor aluminum frame
• Stylus supportDisplay

Main Display

• Foldable Dynamic LTPO AMOLED 2X, 120Hz, HDR10+, 2600 nits (peak)
• Size: 7.6 inches (~91.0% screen-to-body ratio)
• Resolution: 1856 x 2160 pixels (~374 ppi)Cover Display

• Dynamic LTPO AMOLED 2X, 120Hz, 2600 nits (peak)
• Corning Gorilla Glass Victus 2
• Size: 6.3 inches
• Resolution: 968 x 2376 pixels, 410 ppiPlatform

Operating System

• Android 14, One UI 6.1.1 (up to 7 major Android upgrades)Chipset

• Qualcomm SM8650-AC Snapdragon 8 Gen 3 (4 nm)CPU

• 8-core (1×3.39GHz Cortex-X4 & 3×3.1GHz Cortex-A720 & 2×2.9GHz Cortex-A720 & 2×2.2GHz Cortex-A520)

GPU

• Adreno 750 (1 GHz)Memory

Card Slot

• NoInternal Storage

• 256GB 12GB RAM
• 512GB 12GB RAM
• 1TB 12GB RAM
• UFS 4.0Main Camera

Triple Setup

• 50 MP, f/1.8, 23mm (wide), dual pixel PDAF, OIS
• 10 MP, f/2.4, 66mm (telephoto), PDAF, OIS, 3x optical zoom
• 12 MP, f/2.2, 123˚ (ultrawide)

Features

• LED flash, HDR, panoramaVideo

• 8K@30fps, 4K@60fps
• 1080p@60/120/240fps (gyro-EIS)
• 720p@960fps (gyro-EIS)
• HDR10+Selfie Camera

Under Display Camera

• 4 MP, f/1.8, 26mm (wide)Cover Camera

• 10 MP, f/2.2, 24mm (wide)Features

• HDRVideo

• 4K@30/60fps, 1080p@30/60fps (gyro-EIS)Sound

• Stereo speakers
• No 3.5mm jack
• 32-bit/384kHz audio
• Tuned by AKGCommunications

• WLAN: Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, Wi-Fi Direct
• Bluetooth: 5.3, A2DP, LE, aptX HD
• Positioning: GPS, GALILEO, GLONASS, BDS, QZSS
• NFC: Yes
• Radio: No
• USB: Type-C 3.2, OTGFeatures

• Sensors: Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometer
• Samsung DeX (desktop experience)
• Ultra Wideband (UWB) support
• Circle to SearchBattery

Type

• Li-Po 4400 mAhCharging

• 25W wired, 50% in 30 min (QC2.0)
• 15W wireless
• 4.5W reverse wireless

Misc

• Colors: Navy, Silver Shadow, Pink, Black, White
• Models: SM-F956B, SM-F956B/DS, SM-F956U, SM-F956U1, SM-F956N, SM-F956W, SM-F9560
• SAR EU: 1.24 W/kg (head), 1.39 W/kg (body)
• Price: $884.36 / €1,004.60 / £785.00 / ₹119,890Our Tests

• Performance: AnTuTu: 1,608,744 | GeekBench: 6757 | 3DMark: 4644
• Display: 1630 nits max brightness (measured)
• Loudspeaker: -26.5 LUFS (Good)
