Network

Technology

GSM / CDMA / HSPA / EVDO / LTE / 5G

Launch

Announced

2021, September 14

Status

Available. Released 2021, September 24

Body

Dimensions

160.8 x 78.1 x 7.7 mm (6.33 x 3.07 x 0.30 in)

Weight

240 g (8.47 oz)

Build

Glass front, glass back, stainless steel frame

SIM

• Nano-SIM + eSIM
• Nano-SIM + Nano-SIM
• IP68 dust/water resistant (up to 6m for 30 min)
• Apple Pay (Visa, MasterCard, AMEX certified)

Display

Type

Super Retina XDR OLED, 120Hz, HDR10, Dolby Vision, 1000 nits (HBM), 1200 nits (peak)

Size

6.7 inches, 109.8 cm² (~87.4% screen-to-body ratio)

Resolution

1284 x 2778 pixels, 19.5:9 ratio (~458 ppi density)

Protection

Ceramic Shield glass

Platform

OS

iOS 15, upgradable to iOS 18.6

Chipset

Apple A15 Bionic (5 nm)

CPU

Hexa-core (2×3.23 GHz Avalanche + 4×1.82 GHz Blizzard)

GPU

Apple GPU (5-core graphics)

Memory

Card Slot

No

Internal Storage Options

• 128GB 6GB RAM
• 256GB 6GB RAM
• 512GB 6GB RAM
• 1TB 6GB RAM

Type

NVMe

Main Camera

Triple

• 12 MP, f/1.5, 26mm (wide), 1/1.7″, dual pixel PDAF, OIS
• 12 MP, f/2.8, 77mm (telephoto), PDAF, OIS, 3x optical zoom
• 12 MP, f/1.8, 13mm (ultrawide), PDAF
• TOF 3D LiDAR scanner (depth)

Features

Dual-LED dual-tone flash, HDR (photo/panorama)

Video

4K@24/25/30/60fps, 1080p@25/30/60/120/240fps, 10-bit HDR, Dolby Vision HDR (60fps), ProRes, stereo sound

Selfie Camera

Single

12 MP, f/2.2, 23mm (wide), SL 3D (depth/biometrics sensor)

Features

HDR

Video

4K@24/25/30/60fps, 1080p@25/30/60/120fps, gyro-EIS

Sound

Loudspeaker

Yes, with stereo speakers

3.5mm Jack

No

Communications

WLAN

Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, hotspot

Bluetooth

5.0, A2DP, LE

Positioning

GPS, GLONASS, GALILEO, BDS, QZSS

NFC

Yes

Radio

No

USB

Lightning, USB 2.0

Features

Sensors

Face ID, accelerometer, gyro, proximity, compass, barometer

Extra

Ultra Wideband (UWB) support

Battery

Type

Li-Ion 4352 mAh (16.75 Wh)

Charging

• Wired PD2.0, 50% in 30 min
• 15W wireless (MagSafe)
• 15W wireless (Qi2, requires iOS 17.2 update)

Miscellaneous

Colors

Graphite, Gold, Silver, Sierra Blue, Alpine Green

Models

A2643, A2484, A2641, A2644, A2645, iphone14,3

SAR

1.18 W/kg (head), 1.20 W/kg (body)

SAR EU

0.99 W/kg (head), 0.98 W/kg (body)

Our Tests

Performance

• AnTuTu: 801691 (v9)
• GeekBench: 4706 (v5.1)
• GFXBench: 60fps (ES 3.1 onscreen)

Display

1050 nits max brightness (measured)

Camera
